ISOcount Lite
- Particle fall-out monitor
- Ideal for identifying shape and size or larger particles
- Silicon-based sensors
- Differentiates particles from fibres
- Continuous monitoring
- Tracks ≥ 5 µm
- Description
ISOcount Lite provides real-time monitoring of particle fall-out/deposition for cleanrooms. Whilst airborne sensing is ideal for small particles which remain suspended in the air and are removed by filtration, the higher risk to operations can be from particles larger than 5 µm, which are more quickly deposited on surfaces leading to contamination and yield losses.
Featuring Direct Particle Detection (DPD) technology, ISOcount Lite uses high performance silicon sensing to directly monitor particles settling on the surface of the sensor.
Advanced recognition algorithms detect particle size and profile providing particle count by size, percent area covered and a differentiation between fibres and particles. Alarms can be triggered when pre-defined limits are exceeded.
- Automatic particle fall-out monitoring
- Alerts/alarms for exceptions
- Avoid contamination/yield losses
- Track trends - allows continuous tracking with time and room activity
- XCAM direct particle detection technology
- Particle monitoring 5 µm to >750 µm
- Reporting to IEST-STD-CC1246E
- Touchscreen reporting dashboard
- Take action to prevent yield losses part way through a key process
- Identify activities which create higher contamination levels
- Monitor the effects of process improvements
- Assess the effect of new processes
- Automatically collect surface contamination statistics for project reporting
- Additional information
ISOair Lite Size: 178 x 178 x 92 mm
FAQS
Want to know more about how the ISOcount Lite might benefit your controlled environment facility management? Click the plus symbols (right) to check out some of the most Frequently Asked Questions related to this product!
- What are the main benefits of the ISOcount Lite?
It provides real-time monitoring and analysis ensuring particle fall-out trends can be tracked, contamination incidents can be identified as they occur, and the
time and cost of monitoring is reduced by removing the need for samples to be retrieved. - How does it work?
ISOcount Lite uses high performance silicon sensing to directly observe particles settling on the surface of the sensor. Advanced recognition algorithms
detect particle size and profile, providing particle size distribution statistics. - What's the total detection area?
It can detect 4cm squared.
- What's the sample rate and particle detection range?
It takes 10 samples per hour and detects 5 µm to 750 µm.
- What's the operating temperature range?
It can be operated from +20 to +35 °C.
- What size is it?
The ISOcount Lite is 178 x 178 x 92 mm.
- Are there any PC requirements?
Yes, it requires 64-bit, intel core i7, 8 GB of RAM (recommended) and a USB 2.0 interface.
