ISOcount Max
- Elite remote particle counter
- Six particle size channels
- Built-in vacuum pump
- Ultra precise readings
- Lightweight design
- Description
The ISOcount Max Remote Particle Counter is the most feature-advanced remote airborne particle counter available. Integration is easy into a building automation and cleanroom management system via Ethernet, or (optional) Wireless 802.11 b/g, RS485 or RS232.
The particle counter’s display and report 6 user-selectable particle size channels, as well as temperature and relative humidity, flow and sensor status, date of last calibration, serial number, laser on-time and date of manufacture for easy maintenance and warranty management.
This remote particle counter stores up to 45,000 time stamped particle count and environmental data records which provides data redundancy on every instrument. ISOcount Max counters can be controlled and monitored remotely via web browsers for ultra-convenient remote operation.
- Particle Size Range: Detects particles from 0.3 μm to 25 μm
- Flow Rate: 0.1 CFM (2.83 LPM) with built-in vacuum pump
- Simultaneous Channels: Measures up to 6 user-selectable particle size channels
- Environmental Monitoring: Optional temperature and relative humidity probe
- Data Storage: Stores up to 45,000 time-stamped records for redundancy
- Display: 4.3″ (10.9 cm) WQVGA (480×272) color touch screen
- Connectivity: Ethernet and USB; optional Wireless 802.11 b/g, RS485, or RS232
- Compliance: Meets ISO 21501-4 and JIS B9921 standards
- Alarm System: Adjustable internal audible alarm for various alerts
- Construction: Lightweight stainless steel enclosure
- Additional information
Particle Counter ISOcount Max Particle Counter
FAQS
Want to know more about how the ISOcount Max might benefit your controlled environment facility management? Click the plus symbols (right) to check out some of the most Frequently Asked Questions related to this product!
- What particle sizes can the 5301P measure?
The 5301P measures particles from 0.3 μm to 25.0 μm across six user-selectable channels.
- What is the flow rate of the 5301P?
It has a flow rate of 0.1 CFM (2.83 LPM), ideal for remote and continuous cleanroom monitoring.
- Does it require an external vacuum source?
No, it includes an internal vacuum pump, allowing standalone operation.
- Can it monitor environmental conditions too?
Yes, it can measure temperature, relative humidity, and barometric pressure with optional sensors.
- How does it connect to building systems? How does it connect to building systems?
The 5301P supports Ethernet by default, with optional wireless (Wi-Fi), RS232, or RS485 connectivity for easy integration into automation or monitoring systems.
- Is remote access available?
Yes, the unit can be accessed and controlled via a standard web browser from a networked computer.
