ISOhatch Max
- Elite-level active trolley hatch
- Fan Filter Unit mounted in roof panel providing HEPA-filtered air
- High quality stainless steel grade 316 or 304 options
- Tailored to your exact specifications
- Industry-leading design and construction principles
- Description
ISOhatch Max is a high-performance cleanroom trolley hatch, crafted from stainless steel grade 316 or 304, designed for the secure and streamlined transfer of trolleys and large equipment in controlled environments.
Engineered to minimise risks of contamination, pressure fluctuations or unwanted movement between classification zones, ISOhatch Max includes a roof-mounted HEPA Fan Filter Unit (FFU) that generates unidirectional airflow, actively clearing particulates and contaminants during transfer– perfect for transitions between cleanroom environments or sterile and non-sterile areas.
Built with durable, high-performance stainless steel, ISOhatch Max offers smooth, easy-to-clean surfaces, an interlocking system for contamination prevention and flexible customisation to meet the exact requirements of your cleanroom facility.
- HEPA-Filtered Fan Filter Unit (FFU) – integrated HEPA filtration (typically ≥99.99% @ 0.3μm) actively purges the hatch chamber with clean air during operation, significantly reducing the risk of particle transfer
- Grade 316 or 304 stainless steel construction – corrosion-resistant and ideal for cleanroom environments, ensuring durability and longevity even in harsh or sterile settings
- Custom floor-standing design – tailored to your exact specifications, including size and configuration, to seamlessly integrate with your cleanroom layout
- Double-skin fabrication – provides a smooth, crevice-free surface for enhanced hygiene and effortless cleaning, helping meet strict GMP and ISO standards
- Mechanical or electro-mechanical interlock system – ensures only one door can be opened at a time, preventing cross-contamination and preserving pressure differentials between clean zones
- Optional sliding door mechanism – available on one or both sides to optimsze space efficiency and operator convenience, especially useful in confined corridors or busy zones
- Flexible, user-centric design – custom dimensions and optional features allow you to design a solution that works best for your process, space and handling needs
- Long-term cost efficiency – stainless steel durability, combined with low-maintenance construction, results in a longer product life and reduced total cost of ownership
Standard product options
- Grade 316 or 304 stainless steel
- UV Lights
- Fire-rated hatch
- Electro-mechanical interlock
- Internal support shelves – glass or stainless steel
- Powder-coated finish
- Conveyor systems to client specification
- Stainless steel support frame
- Additional information
Dimensions N/A Material Grade 304 stainless steel, Grade 316 stainless steel
Sizes 910mm width x 1140mm depth x 1180mm height, Request size
FAQS
Want to know more about how the ISOhatch Max might benefit your controlled environment? Click the plus symbols (right) to check out some of the most Frequently Asked Questions related to this product!
- What makes ISOhatch Max different from other trolley hatches?
Unlike passive hatch models, ISOhatch Max is an active cleanroom transfer hatch equipped with a roof-mounted HEPA Fan Filter Unit (FFU). This creates unidirectional airflow inside the chamber, actively purging particulates and contaminants during every transfer – ideal for transitions between sterile and non-sterile areas.
- What level of filtration does the HEPA FFU provide?
The integrated HEPA filter achieves ≥99.99% efficiency at 0.3μm, ensuring that particles are rapidly flushed from the chamber and reducing the risk of contamination between cleanroom zones.
- What materials is ISOhatch Max built from?
The hatch is manufactured from 304 or 316 stainless steel, providing excellent corrosion resistance, durability, and long-term cleanroom compatibility. 316 stainless steel is recommended for sterile or highly aggressive environments.
- How does the interlock system improve safety?
ISOhatch Max is equipped with a mechanical or electro-mechanical interlock system to ensure that both doors cannot be opened at the same time. This prevents cross-contamination, maintains room pressure differentials, and safeguards process integrity.
- Is it easy to clean and maintain?
With double-skin stainless steel fabrication and smooth, crevice-free surfaces, ISOhatch Max is designed for GMP compliance and effortless cleaning. Its robust construction also ensures a long product lifecycle with minimal maintenance.
